EN 10216-1 seamless tube
The following items are the relative products of the EN 10216-1, you can quickly find the EN 10216-1 through the list.
EN 10216-1: Seamless steel tubes for pressure purposes – Technical delivery conditions – Part 1: Non-alloy steel tubes with specified room temperature properties
Size (mm):
- Outer Dimensions: 6.0mm – 219.0mm
- Wall Thickness: 1.0mm – 30 mm
- Length: max 12000mm
Application: It is used for manufacturing pipeline,vessel,equipment,pipe fittings .
The main products of steel / steel grade:
- EN10216-1 P195
- EN10216-1 P235
- EN10216-1 P265
Packing: Bare/bundles/crates/crate protection at the both sides of tubes or as per customers’ requirements .
Painting: as requested.
The composition of this steel makes it ideal for applications where elevated working temperatures are the norm and the material is used by fabricators throughout the oil, gas and petrochemical industry.
EN10216-1: Chemical Compositions(%)
| Grade | C | Si | Mn | P | S | Cr | Mo | Cu | Ni |
| P195 | ≤0.13 | ≤0.35 | ≤0.70 | ≤0.025 | ≤0.020 | ≤0.030 | ≤0.08 | ≤0.30 | ≤0.30 |
| P235 | ≤0.16 | ≤0.35 | ≤1.20 | ≤0.025 | ≤0.020 | ≤0.030 | ≤0.08 | ≤0.30 | ≤0.30 |
| P265 | ≤0.20 | ≤0.40 | ≤1.40 | ≤0.025 | ≤0.020 | ≤0.030 | ≤0.08 | ≤0.30 | ≤0.30 |
DIN10216-1: Mechanical Properties
| Grade | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation(%)L | Elongation (%)T |
| P195 | ≥195 | 320-440 | 27 | 25 |
| P235 | ≥235 | 360-500 | 25 | 23 |
| P265 | ≥265 | 410-570 | 21 | 19 |
Our heat exchanger for pressure vessel equipment is good in quality and competitive in price. We manufacture heat exchanger for pressure vessel equipment and supply OEM, ODM service according to your requirement.
